Samsung SAMTRON 78BDF Computer Monitor User Manual



(The configuration at the back of the monitor may vary from product to product.)
Power port
Connect the power cord for your monitor to the power port on
the back of the monitor.
Signal Cable
Connect the signal cable to the video port on your computer,
video board, video card, or graphics card.
See Connecting the Monitor for further information regarding cable connections.
Bottom
Signal Cable
Connect the signal cable to the video port on your computer,
video board, video card, or graphics card.
Power port
Connect the power cord for your monitor to the power port on
the back of the monitor.
Tilt/Swivel Base
You can separate the base from the monitor.
