SIM2 HT 300E / HT 280E
RS-232C CONTROL SPECIFICATIONS
10
INCREMENT
BE EF 03 19 00 6B 9F 03 1E 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
KEYSTONE
HORIZONTAL
DECREMENT
BE EF 03 19 00 05 35 04 1E 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET ENGLISH
BE EF 03 19 00 15 35 01 05 24 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET ITALIANO
BE EF 03 19 00 85 F4 01 05 24 00 00 00 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET FRANCAIS
BE EF 03 19 00 74 B4 01 05 24 00 00 00 00 00 00
02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET DEUTSCH
BE EF 03 19 00 E4 75 01 05 24 00 00 00 00 00 00
03 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET ESPANOL
BE EF 03 19 00 D6 37 01 05 24 00 00 00 00 00 00
04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
LANGUAGE
SET PORTUGUES
BE EF 03 19 00 46 F6 01 05 24 00 00 00 00 00 00
05 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
INCREMENT
BE EF 03 19 00 82 88 03 61 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
OSD POSITION
HORIZONTAL
DECREMENT
BE EF 03 19 00 EC 22 04 61 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
INCREMENT
BE EF 03 19 00 7D 6C 03 62 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
OSD POSITION
VERTICAL
DECREMENT
BE EF 03 19 00 13 C6 04 62 08 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET YCrCb
AutoSync
BE EF 03 19 00 92 04 01 82 08 00 00 00 00 00 00
14 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET YCrCb 15kHz
BE EF 03 19 00 5B 0C 01 82 08 00 00 00 00 00 00
08 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET YCrCb 32kHz
BE EF 03 19 00 51 06 01 82 08 00 00 00 00 00 00
10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET RGB AutoSync
BE EF 03 19 00 97 01 01 82 08 00 00 00 00 00 00
18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SET RGB 15kHz
BE EF 03 19 00 5E 09 01 82 08 00 00 00 00 00 00
04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
INPUT 3
(COMP. RGB) /
SIGNAL TYPE
SET RGB 32kHz
BE EF 03 19 00 98 0E 01 82 08 00 00 00 00 00 00
0C 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
RECALL
BE EF 03 19 00 85 EB 01 27 09 00 00 01 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SAVE CURRENT
SETTINGS
BE EF 03 19 00 54 D6 01 27 09 00 00 00 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
MEMORY 1
SAVE INITIAL
SETTINGS
BE EF 03 19 00 45 9A 01 28 09 00 00 01 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
RECALL
BE EF 03 19 00 74 AB 01 27 09 00 00 01 00 00 00
02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SAVE CURRENT
SETTINGS
BE EF 03 19 00 A5 96 01 27 09 00 00 00 00 00 00
02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
MEMORY 2
SAVE INITIAL
SETTINGS
BE EF 03 19 00 76 DE 01 28 09 00 00 02 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
RECALL
BE EF 03 19 00 E4 6A 01 27 09 00 00 01 00 00 00
03 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
SAVE CURRENT
SETTINGS
BE EF 03 19 00 35 57 01 27 09 00 00 00 00 00 00
03 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
MEMORY 3
SAVE INITIAL
SETTINGS
BE EF 03 19 00 A7 E3 01 28 09 00 00 03 00 00 00
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
