Sony VPLEX175 Projector User Manual



34
Specifications
INPUT OUTPUT
(Computer/video)
S VIDEO (S
VIDEO IN)
S video input connector: Mini DIN 4-pin, Y: 1 Vp-p ± 2
dB, sync negative, 75 ohmes terminated, C: (burst signal)
0.286 (NTSC)/0.3 (PAL/SECAM) Vp-p ± 2 dB, 75 ohms
terminated
Audio input connector: Phono jack × 2, rated input
500 mVrms, Input impedance more than 47 kohms
VIDEO (VIDEO
IN)
Video input connector: Phono jack, 1 Vp-p ± 2 dB,
sync negative, 75 ohmes terminated
Audio input connector: Shared with S VIDEO IN
OUTPUT MONITOR output connector: Mini D-sub 15-pin
female, G with sync/Y: 1 Vp-p ± 2 dB, sync negative, 75
ohms terminated, RGB/P
BPR: 0.7 Vp-p ± 2 dB, 75 ohms
terminated, Sync signal: HD, VD 4 V (open), 1 Vp-p (75
ohms), positive/negative
Audio output connector: Stereo mini jack, stereo, 1
Vrms (maximum volume, when inputting 500 mVrms),
output impedance 5 kohms
Others connector RS-232C connector: D-Sub 9 pin female
LAN connector (VPL-EX145/EX175 only): RJ45,
10BASE-T/100BASE-TX
Operating
temperature/
Operating
humidity
0 °C to 40 °C (32 °F to 104 °F)/35% to 85% (no
condensation)
Storage
temperature/
Storage humidity
–20 °C to +60 °C (–4 °F to +140 °F)/ 10% to 90%
Power
requirements
VPL-EX100/EX120: 100 V to 240 V AC, 3.0 A-1.5 A,
50/60 Hz
VPL-EX145/EX175: 100 V to 240 V AC, 3.2 A-1.6 A,
50/60 Hz
Power
consumption
VPL-EX100/EX120:
100 V AC: 300 W
240 V AC: 290 W
VPL-EX145/EX175:
100 V AC: 320 W
240 V AC: 310 W
Standby power VPL-EX100/EX120:
100 V AC: 8 W (when “Standby Mode” is set to
“Standard”)/1 W (when “Standby Mode” is set to “Low”)
240 V AC: 10 W (when “Standby Mode” is set to
“Standard”)/1 W (when “Standby Mode” is set to “Low”)
VPL-EX145/EX175:
100 V AC: 9 W (when “Standby Mode” is set to
“Standard”)/1 W (when “Standby Mode” is set to “Low”)
240 V AC: 11 W (when “Standby Mode” is set to
“Standard”)/1 W (when “Standby Mode” is set to “Low”)
Item Description
Model VPL-EX100/EX120/EX145/EX175
