Agilent E1439 Programmer's Reference
Functions listed alphabetically
age1439_interrupt_restore (on page 145) −restores the interrupt masks to the most recent
setting
age1439_interrupt_setup (on page 146) −sets both interrupt parameters
age1439_lbus_mode (on page 148) −sets the local bus transmission mode
age1439_lbus_mode_get (on page 148) −gets the local bus mode
age1439_lbus_reset (on page 150) −resets local bus
age1439_lbus_reset_get (on page 150) −gets the local bus mode reset state
age1439_meas_control (on page 151) −initiates and controls measurements in multi-
module systems
age1439_meas_init (on page 154) −initiates a measurement without first checking for
valid hardware setup
age1439_meas_start (on page 155) −checks for valid hardware setup and then initiates a
measurement
age1439_meas_status_get (on page 156) −returns the current measurement status.
age1439_options_get (on page 157) −returns the module’s options
age1439_product_id_get (on page 158) −returns the module’s product identification
string
age1439_read (on page 159) −reads scaled 32-bit float data from FIFO
age1439_read_raw (on page 162) −reads raw data from FIFO
age1439_read64 (on page 159) −reads scaled 64-bit float data from FIFO, specifically for
VEE applications
age1439_reference_clock (on page 165) −selects the source of the reference clock
age1439_reference_clock_get (on page 165) −gets the source of the reference clock
age1439_reference_prescaler (on page 166) −selects prescaling of the reference clock
age1439_reference_prescaler_get (on page 166) −gets prescaling of the reference clock
age1439_reset (on page 167) −places the module in a known state
age1439_reset_hard (on page 168) −resets the module hardware
age1439_revision_query (on page 169) −returns strings that identify the date of the firm-
ware revision.
age1439_self_test (on page 170) −performs a self-test on the module and returns the result
age1439_serial_number (on page 157) −sets the module’s serial number for product
repair purposes
age1439_serial_number_get (on page 157) −returns the module’s serial number
age1439_smb_clock_output (on page 173) −specifies which clock to output from the
SMB clock connectors
age1439_smb_clock_output_get (on page 173) −gets which clock to output from the
SMB clock connectors
age1439_state_save (on page 175) −saves the current module state
age1439_state_recall (on page 174) −recalls a saved module state
age1439_status_get (on page 176) −retrieves module's status register information
age1439_sync_clock (on page 178) −selects the source of the sync signal
age1439_sync_clock_get (on page 178) −gets the source of the sync signal
age1439_sync_direction (on page 179) −selects front or rear panel availability of the sync
signal
age1439_sync_direction_get (on page 179) −gets the state of front or rear panel clock
availability
age1439_sync_output (on page 180) −selects the output for the sync signal
age1439_sync_output_get (on page 180) −gets the output for the sync signal
age1439_trigger_adclevel (on page 183) −specifies the threshold for the ADC trigger
age1439_trigger_adclevel_get (on page 183) −gets the trigger threshold
age1439_trigger_delay (on page 183) −specifies a pre- or post-trigger delay time
age1439_trigger_delay_actual_get (on page 181) −gets the actual delay time from the
