Accessories Supplied
The HP 16500H is shipped with the following accessories:
•
this
Installation and Service Guide
•
a
LAN Administrator’s and Service Guide
•
a
LAN User’s Guide
•
screws and one cable to install the HP 16500H into the HP 16500B
mainframe
•
TORX 10 and TORX 15 wrenches
If your HP 16500H was installed into the HP 16500B by HP, you will
not receive these tools. If your HP 16500H was not installed by HP,
you will receive these tools.
Requirements
HP 16500B Logic Analysis System mainframe, and one of the following:
•
NFS or FTP capabilities on your TCP/IP Ethernet LAN, or
•
HP 16501A Expansion Frame, or
•
HP 16505A Prototype Analyzer
Physical Connections
•
RJ-45 connector for direct connection to 10Base-T networks
•
68-pin D-connector for connection to an HP 16501A Expansion Frame
•
High-speed port for connection to an HP 16505A Prototype Analyzer
Introducing the HP 16500H Interface Module
