Hardware Specifications
Standards Compliance: IEEE802.3/802.3ab / 802.3z / 802.3u / 802.3x
Network Interface:
Configuration Mode Connector Port
10/100/1000Mbps Gigabit copper
Nway
TP (RJ-45)
1
1–8
1000Base-SX Gigabit Fibre
1000 FDX
SFP
2
7, 8
1000Base-LX Gigabit Fibre
1000 FDX
SFP
2
7, 8
1000Base-LX Single Fibre WDM
1000 FDX
SFP
2
7, 8
Notes: 1: Ports 7 & 8 are paired copper TP RJ-45/SFP fibre module slot dual media ports.
Only one port from each pair can be used at any given point. The paired ports
have an auto- detect feature
2: SFP module slots are used to install optional mini-GBIC modules, primarily
for fibre Gigabit Ethernet connectivity. Optional SFP mini-GBIC modules
support LC or WDM SC transceivers in multimode or singlemode varieties.
See section 1.5 for details of Alloy mini-GBIC module products
Transmission Mode: * 10/100Mbps supports full or half duplex
* 1000Mbps supports full duplex only
Transmission Speed: * 10/100/1000Mbps for Copper
* 1000Mbps for Fibre (SFP)
Full Forwarding/Filtering * PPS (packets per second)
Packet Rate:
Forwarding Rate Speed
1,488,000PPS 1000Mbps
148,800PPS 100Mbps
14,880PPS 10Mbps
MAC Address and * 8K MAC address
Self-learning: 4K VLAN table entries,
Buffer Memory: * Embedded 144 KB frame buffer
Flow Control: * IEEE802.3x compliant for full duplex
* Backpressure flow control for half duplex
