MVP-5100/5150 Modero Viewpoint Touch Panels
MVP-5150 Specifications (FG5966-07) (Cont.)
External Components
Connector: 5-pin Mini-USB connector used for output to USB programming, firmware
update, and touch panel file transfer between the PC and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible)
cable, be sure to power the panel On before attempting to connect the USB
cable from the PC to the mini-USB port on the panel.
DC power port: 2.5 mm port to power the panel away from a Charging Station.
Speaker: • 4 Ohm
• 2 Watts 300Hz cutoff frequency
• NOTE: Speaker is only used for feedback beeps, and will not transmit
standard audio.
Audio Standards: • G.711 sound standard
• 75dB SPL@1m
IR Emitters: Transmit IR over 20 feet (6.10 m) from the panel.
• IR emitters on G4 panels share the device address number of the panel.
• Transmits AMX fixed frequencies at 38KHz and 455KHz and 8 user-
programmable frequencies from 20KHz to 1.5MHz
Operating/Storage
Environment
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 5% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories: • MVP-5150 Installation Guide (93-5966-08)
• PS3.0 Power Supply (FG423-30)
Other AMX Equipment: • MVP-TCS-52: Table Charging Station (FG5966-1X)
• MVP-WCS-52: Wall Charging Station (FG5966-1X)
• MVP-BP-51S, Standard Capacity Replacement Battery Pack Kit (FG5966-
25K)
• MVP-BP-51H, High Capacity Replacement Battery Pack Kit (FG5966-24K)
• MVP-STYLUS-52: Stylus, Pack of 3 (FG5966-30-xx)
• CC-USB: USB Programming Cable (FG10-5965)
• MVP-HP USB 1/8" Adapter (FG5966-23)
1.2.
This device complies with FCC Part 15 and Industry Canada RSS 210 subject to the
following conditions:
1. This device must not cause harmful interference and
2. This device must accept all interference, including interference that interferes with
the operation of this device.
