MVP-5100/5150 Modero Viewpoint Touch Panels
MVP-5150 5.2" Modero ViewPoint WiFi Touch Panel
MVP-5150 Specifications (FG5966-07)
Dimensions: 4 3/4" x 7 9/16" x 13/16" (120.7 mm x 191.8 mm x 20.3 mm)
Weight: • 1.25 lbs (0.57 kg)
Enclosure: Matte black plastic.
Power Requirements
(Without Charging):
Panel with battery fully charged:
• Constant current draw: 0.3 A @ 12 VDC
• Startup current draw: 0.4 A @ 12 VDC
Power Requirements
(While Charging):
Panel while charging battery:
• Constant current draw: 1.1 A @ 12 VDC
• Startup current draw: 1.3 A @ 12 VDC
Minimum Power Supply
Required:
• PS3.0 Power Supply (FG423-30) - both 120 VAC and 240 VAC models are
shipped with this power supply
Power Modes: • AWAKE: All necessary modules are powered up and device remains online
with the Netlinx Master.
• ASLEEP: Only the backlight will be turned off after the user selectable time of
inactivity has elapsed. Panel resumes the Awake mode in ~ 1 second
upon a momentary press of the touchscreen.
• PROCESSOR SHUTDOWN: Power to all peripherals and components is
turned off. The system remains in this mode until it is rebooted. The panel is
re-activated by pressing the touchscreen and holding until the AMX splash
screen appears.
Certifications: • FCC Part 15 Class B
•CE
• IEC/EN-60950
•RoHS
• Japan Approved
• Lithium polymer microbattery: UN/IATA
Battery Duration: • 2.5 days of normal use, in a combination of Awake and Shutdown Modes.
• Three hours of continuous use (continuous Awake state).
Memory:
• 128 MB Mobile DDRAM (upgrade not available)
• 256 MB NAND Flash (upgrade not available)
Panel LCD Parameters: • Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Type: WVGA
• Aspect ratio: 16 x 9
• Brightness (luminance): 300 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 400:1
• Display colors: 262,144 colors (18-bit color depth)
• Dot/pixel pitch: 0.23 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Viewing angles:
Vertical: + 40° (up from center) and - 80° (down from center)
Horizontal: + 60° (left from center) and - 60° (right from center)
