USB-Disk Module
AP-UMxxxxXXXXG-XXXX
2
© 2008 Apacer Technology, Inc. Rev.
1.0
FEATURES:
• USB2.0 High-Speed and USB1.1 Full-
Speed compatible interface
• Capacity
– 256, 512MB
– 1, 2, 4, 8GB
1
• Fast sustained read performance
– Sustained read: 30 MB/s
• Fast sustained write performance
– Sustained write: 20 MB/s
• Intelligent USB Module
– Implements dynamic wear-leveling
algorithms to substantially increase
longevity of flash media
– 4-bit Error Detection Code/Error Correction
Code (EDC/ECC)
– Intrinsic data integrity after power loss
– Wear leveling algorithm that provides more
reliable data storage over an extended
period
• Extended Data Protection (Optional)
– Write protection setting by jumper for
prevention of data overwrites.
• Zero Power Data Retention
– Batteries not required for data storage
• Support Ready Boost for Windows Vista
• Support boot-up function for OS
– Windows XP Embedded
– Windows CE
– Linux
• Temperature ranges
– 0°C to 70°C for operation (standard)
– -40°C to 85°C for operation (ET
2
)
– -40°C to 100°C for storage
• Low power consumption (typical)
– Active mode: 110 mA
– Sleep mode: 450 μA
• Connector
– 10-pin (2x5) female header
• RoHS Compliant
1. Standard Temperature only
2. Extended Temperature
