ENGLISH
A05-15AM-E01_X02 11 - 44
Follow these steps to pack the monitor:
Disconnect the AC adapter, signal cable, and any cables connected to the monitor.
Tile the panel backward to approx. 25°.
Slide the latch outward and hold it in place 1.
NOTE: Do not tilt the LCD beyond the allowed angles without first sliding the latch to the right.
Doing so may damage the hinge arm.
Then, you can keep on tilting the panel to the horizontal position 2 for packing into a
carton.
5 Specifications :
Size 15.0" (full 15.0" viewable diagonal area)
Type TFT (Thin Film Transistor), Active Matrix Panel
Pixel Pitch 0,297 x 0.297 mm
Color 16.7 M
Brightness 200 cd/m
2
Contrast 300:1
View Angle +/- 60( H) . 45(UP)/55(DOWN) at CR>10
Response Time <20ms
LCD
Glass surface Anti-Glare & Hard Coat 2H
Input Signal Video RGB Analog
Sync H. V., Separate Sync,
Horizontal Frequency 30-62kHz,
Vertical Frequency 50-75Hz,
Video Sync
Video Bandwidth 80MHz
Audio Speakers 2W x 2
Resolution Primary Mode 1024 x 768
Power Voltage 12V / 3.5A
Connector Input Signal D-SUB (15Pin)
Display Area Full screen 304.1 x 228.1 mm
Temperature 0 ~ + 4 5 Operating
Conditions
Humidity 10% ~ 90%
Temperature -20 ~ + 60 °C Storage
Conditions
Humidity 95%
Physical 365(W) x 175(D) x 365(H)mm
Dimensions
Package 430(W) x 135(D)x 525(H)mm
Net: 3.5Kg.
Weight
Gross: 4.5Kg.
Safety CE, FCC
Low Radiation Yes
Energy Star Yes
Environment Yes
Regulations
Quality ISO 13406-2 Class II
On <30W
Power saving
Off <8W
Customer se
If you have any que
please contact us a
Customer service p
Customer service e
Website://www.amp
mplux Techn
7F, #838 Ching K
Taiwan.
Tel: 886-3-358-98
Fax: 886-3-358-9
e-mail: amplux.co
http://www.amplu
