AXIS Q87-E 230/120 V AC Installation Guide Page 5
ENGLISH
AXIS Q87-E Power Supply 230 V AC &
AXIS Q87-E Power Supply 120 V AC
Installation Guide
This Installation Guide provides instructions for connecting AXIS Q87-E Power Supply 230/120 V AC
with AXIS Q87-E Dual PTZ Network Camera Series.
Installation Steps
1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3. Install the Power Supply. See page 7.
Package Contents
Item Models/variants/notes
Power Supply Power supply (230/120 V AC) with built-in day/night sensor
Printed materials AXIS Q87-E 230/120 V AC Installation Guide (this document)
Tools needed (not included) Ratchet set
Drill for drilling holes in mounting surface
