2. Hardware Orientation
PDS Rear Panel
• 1920x1200@60 (193.25 MHz)
• 2048x1080p@60 (183.75 MHz)
~ Composite and S-Video formats are supported.
In Chapter 3, refer to the “Format Connection Table
” section on page 22 for a
table of analog inputs that you can connect using a customer-supplied breakout
cable. In Appendix A, refer to the “Analog 15-pin D Connector
” section on
page 124 for pinouts.
2) DVI and Analog Inputs
Four DVI-I connectors are provided on the PDS-902 and PDS-901, and two on the
PDS-701, for both digital and analog inputs.
~ Using the connector’s digital pins, an 8-bit digital input is supported.
~ Using the connector’s analog pins, RGBHV, analog composite, S-Video,
and YUV formats are supported. A customer-supplied breakout cable or
DVI to HD-15 adapter is required for these connections.
In Appendix A, refer to the “DVI-I Connector” section on page 125 for pinouts.
3) 3G/HD/SD SDI Input
One BNC connector is provided for the SD-SDI, HD-SDI, or 3G-SDI input.
4) Main Outputs
Two connectors are provided for the PDS’s main program outputs. Both outputs
have the same resolution, and both can be used simultaneously.
~ One DVI-I connector is provided for the system’s digital program output.
There are no analog outputs on this connector. In Appendix A, refer to
the “DVI-I Connector
” section on page 125 for pinouts.
~ One HD-15 connector is provided for the system’s analog output. In
Appendix A, refer to the “Analog 15-pin D Connector” section on
page 124 for pinouts
5) Ethernet
One RJ-45 connector is provided for 10/100BaseT Ethernet communications with
the PDS system. The port is used for running the built-in web-based GUI, for
diagnostics, or for command-line operations via Telnet (using port 23).
telnet 192.168.0.10 23
In Appendix A, refer to the “Ethernet Connector
” section on page 126 for
pinouts.
6) AC Power
One AC Connector is provided for connecting PDS to AC. The integral switch
turns the chassis on and off. In Appendix A, refer to the “Physical and Electrical
Specifications” section on page 123 for power details.
7) Preview Outputs
Two outputs are provided on the PDS-902 for connecting to the Preview monitor:
an HD-15 connector for analog monitors and a DVI connector for digital displays.
8) Serial
Note
The DVI-I connector allows you to use both DVI-D and DVI-I
cables as required.
