List6(PANEL ASSY)

REF. NO.

PART CODE

QTY.

DESCRIPTION

REMARKS

1

LE3539001

1

CONTROL PANEL ASSY, MFC830 FOR GER/AUT

1

LE3541001

1

CONTROL PANEL ASSY, MFC830 FOR UK/BEL/CHE

1

LE3550001

1

CONTROL PANEL ASSY, MFC830 FOR FRA

1

LE3684001

1

CONTROL PANEL ASSY, MFC830 FOR NOR

1

LE3686001

1

CONTROL PANEL ASSY, MFC830 FOR DEN

1

LE3688001

1

CONTROL PANEL ASSY, MFC830 FOR SPA

1

LE3690001

1

CONTROL PANEL ASSY, MFC830 FOR ITA

1

LE3692001

1

CONTROL PANEL ASSY, MFC830 FOR SWE

1

LE3560001

1

CONTROL PANEL ASSY, MFC840 FOR GER

1

LE3571001

1

CONTROL PANEL ASSY, MFC840 FOR UK/BEL/CHE/IRE/ZAF

1

LE3578001

1

CONTROL PANEL ASSY, MFC840 FOR FRA

1

LE3711001

1

CONTROL PANEL ASSY, MFC840 FOR NOR

1

LE3713001

1

CONTROL PANEL ASSY, MFC840 FOR NLD

1

LE3715001

1

CONTROL PANEL ASSY, MFC840 FOR DEN

1

LE3717001

1

CONTROL PANEL ASSY, MFC840 FOR SPA

1

LE3849001

1

CONTROL PANEL ASSY, MFC840 FOR ITA

1

LE3719001

1

CONTROL PANEL ASSY, MFC840 FOR SWE

1-1

LE3540001

1

CONTROL PANEL, MFC830 FOR GER/AUT

1-1

LE3542001

1

CONTROL PANEL, MFC830 FOR UK/BEL/CHE

1-1

LE3551001

1

CONTROL PANEL, MFC830 FOR FRA

1-1

LE3685001

1

CONTROL PANEL, MFC830 FOR NOR

1-1

LE3687001

1

CONTROL PANEL, MFC830 FOR DEN

1-1

LE3689001

1

CONTROL PANEL, MFC830 FOR SPA

1-1

LE3691001

1

CONTROL PANEL, MFC830 FOR ITA

1-1

LE3693001

1

CONTROL PANEL, MFC830 FOR SWE

1-1

LE3561001

1

CONTROL PANEL, MFC840 FOR GER

1-1

LE3572001

1

CONTROL PANEL, MFC840 FOR UK/BEL/CHE/IRE/ZAF

1-1

LE3579001

1

CONTROL PANEL, MFC840 FOR FRA

1-1

LE3712001

1

CONTROL PANEL, MFC840 FOR NOR

1-1

LE3714001

1

CONTROL PANEL, MFC840 FOR NLD

1-1

LE3716001

1

CONTROL PANEL, MFC840 FOR DEN

1-1

LE3718001

1

CONTROL PANEL, MFC840 FOR SPA

1-1

LE3850001

1

CONTROL PANEL, MFC840 FOR ITA

1-1

LE3720001

1

CONTROL PANEL, MFC840 FOR SWE

1-2

LE3607001

1

LIGHT SHIELD FILM

1-3

LE4073003

1

TEN KEY, GRAY(1495)

1-4

LE3468001

1

SET KEY, PURPLE(6255)

1-5

LE4078001

1

FUNCTION KEY, PURPLE(6255)

1-6

LE3295001

14

CYLINDRICAL KEY, GRAY(1495)

1-7

UF9954006

4

ONE TOUCH DIAL KEY, (GRAY1495)

1-8

LE4074001

1

START KEY, PURPLE(6255)

1-9

LE4075002

1

STOP KEY, GRAY(1495)

1-10

LJ4285001

1

COLOR COPY KEY, GREEN(5159)

1-11

LJ4231003

1

MONO COPY KEY, GRAY(1495)

1-12

LG2615001

1

CONTROL PANEL PCB

1-13

LG2567001

1

LCD

1-14

LG2617001

1

FPC KEY

1-15

LE3298001

1

PANEL REAR COVER

1-16

LE3330001

1

SPRING PLATE B

1-17

LE3299001

1

SEPARATION RUBBER

1-18

LE3300001

1

SPRING PLATE A

1-19

LE3323001

2

ADF GUIDE CAP

1-20

UF5034001

1

TAPTITE, B 3X6

1-21

UU7107001

1

DOCUMENT FRONT SENSOR ACTUATOR

1-22

UU7108001

1

DOCUMENT REAR SENSOR ACTUATOR

1-23

UU2057001

1

DOCUMENT PRESSURE BAR SPRING

1-24

LE6342001

1

DOCUMENT PRESSURE BAR

1-25

087310816

2

TAPTITE, CUP B M3X8

1-26

LE1071001

1

ANTI-STATIC BRUSH

2

LE3529001

1

LCD PLATE, MFC830 FOR GER/AUT

2

LE3543001

1

LCD PLATE, MFC830 FOR UK/FRA/NOR/BEL/CHE/DEN/SPA/ITA/SWE

2

LE3562001

1

LCD PLATE, MFC840 FOR GER

2

LE3573001

1

LCD PLATE, MFC840 FOR UK/FRA/NOR/BEL/NLD/CHE/IRE/

DEN/SPA/ITA/ZAF/SWE

3

LE3324001

1

ADDRESS LABEL

4

LG2618001

1

PANEL-MAIN HARNESS

MFC830, MFC840
