15
Macintosh
Wired Network
Windows
®
Macintosh
Wired Network
For Macintosh Wired Network Interface Cable Users
(HL-3150CDN / HL-3150CDW / HL-3170CDW)
9
Before you install
a Make sure your machine is connected to an AC
power source and your Macintosh is ON. You
must be logged on with Administrator rights.
b Remove the protective cap from the Ethernet
port marked with a symbol on your
machine.
c Connect the network interface cable to the
Ethernet port, and then connect it to a free port
on your hub.
d Make sure your machine is turned on.
10
Install the printer driver
a Put the CD-ROM into your CD-ROM drive, and
then double-click the BROTHER icon on your
desktop.
b Double-click the Start Here OSX icon. If
prompted, select your model.
c (HL-3150CDW / HL-3170CDW)
Choose Wired Network Connection
(Ethernet), and then click Next.
d The installation screens appear one after
another. If prompted, follow any on-screen
instructions.
e Choose your machine from the list, and then
click Next.
f When the Add Printer screen appears, click
Add Printer.
For users of Mac OS X v10.6.7 or lower: upgrade
to Mac OS X v10.6.8, 10.7.x, 10.8.x. (For the
latest drivers and information for the Mac OS X
you are using, visit http://solutions.brother.com/
.)
It may take a few minutes for the installation to
complete.
• If there is more than one of the same model
connected on your network, the IP Address will
be displayed to help you identify the machine.
• You can find your machine’s IP Address by
printing out the Printer Settings Page (see Print
the Printer Settings Page on page 31).
