59
Appendixes
Item Description
Ribbon Recommended ribbon B110A Ricoh
Max. ribbon width 174.0 mm 6.85 inch
Min. ribbon width 50.0 mm 1.97 inch
Max. ribbon length 360.0 m 1,181 ft
Max. roll diameter 74.0 mm 2.90 inch
Inner diameter of the
paper core
25.4 ± 0.25 mm 1.00 ± 0.01 inch
Outer diameter of the
paper core
33.4 ± 0.5 mm 1.31 ± 0.02 inch
Ribbon end tape length Max. 80.0 mm 3.15 inch
Ribbon end detection Ribbon out detection by a tension sensor
Bar code
(for Datamax® emulation)
One-dimension • Code 3 of 9 • UPC-A • UPC-E • EAN-13 (JAN-13) • EAN-8 (JAN-8)
• Interleaved 2 of 5 • Code 128 • HIBC (Modulus 43-used code 3 of 9)
• Codabar (NW-7) • Int 2 of 5 (Modulus10-used Interleaved 2 of 5)
• Plessey • Case Code • UPC 2DIG ADD • UPC 5DIG ADD • Code 93
• Telepen • ZIP • UCC/EAN128 • UCC/EAN128 (for K-MART)
• UCC/EAN128 Random Weight • FIM
Two-dimension • UPS Maxi Code • PDF-417 • Data Matrix • QR Code • Aztec • RSS
Bar code
(for Zebra® emulation)
One-dimension • Code 11 • Interleaved 2 of 5 • Code 39 • EAN-8 • UPC-E • Code 93
• Code 128 • EAN-13 • Industrial 2 of 5 • Standard 2 of 5
• ANSI CODABAR • LOGMARS • MSI • Plessey • UPC/EAN Extensions
• UPC-A • POSTNET • Planet
Two-dimension • Code 49 • PDF-417 • CODA BLOCK • UPS Maxi Code
• Micro PDF-417 • Data Matrix • QR Code • RSS • TLC39 • Aztec
Font
(for Datamax® emulation)
1. Seven kinds of xed pitch font
• Overseas, English fonts and European fonts
2. OCR fonts OCR-A
*4
, OCR-B
*4
3. Proportional fonts
CG Triumvirate smooth font
CG Triumvirate Bold smooth font
(6, 8, 10, 12, 14, 18, 24, 30, 36, 48 points)
• Character set: Conforms with code page 850 standards
4. True type™ rasterizer
*5
Font
(for Zebra® emulation)
1. Five kinds of xed pitch font
• Overseas, English fonts and European fonts
2. OCR fonts
OCR-A
*4
, OCR-B
*4
3. Proportional font
CG Triumvirate Condensed Bold
4. True type™ rasterizer
*5
Specications
