Installing the Hardware
Step 1
Step 2
Connect one end of an Etherne cable (included with your package)
to the LAN port on the DAP-3220 and the other end of the Ethernet
cable to the port labeled P+DATA OUT on the PoE base unit.
Connect another Ethernet cable from the DATA IN port on the PoE
base unit to your router/switch or to a PC.
Attach the power adapter to the connector labeled POWER IN on the PoE base unit.
Attach the power cord to the power adapter and into an electrical outlet.
Step 3
