xStack DES-6500 Modular Layer 3 Chassis Ethernet Switch CLI Manual
19
IGMP SNOOPING COMMANDS
The IGMP Snooping commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the
following table.
Command Parameters
config igmp_snooping [<vlan_name 32> | all] {host_timeout <sec 1-16711450> |
router_timeout <sec 1-16711450> | leave_timer <sec 1-
16711450> | state [enable | disable]}
config igmp_snooping
querier
[<vlan_name 32> | all] {query_interval <sec 1-65535> |
max_response_time <sec 1-25> | robustness_variable <value 1-
255> | last_member_query_interval <sec 1-25> | state [enabled |
disabled]}
enable igmp_snooping {forward_mcrouter_only}
disable igmp_snooping {forward_mcrouter_only}
config router_ports <vlan_name 32> [add | delete] <portlist>
config
router_ports_forbidden
<vlan_name 32> [add | delete] <portlist>
show router_ports {<vlan_name 32>} {static | dynamic | forbidden}
show igmp_snooping {vlan<vlan_name 32>}
show igmp_snooping
group
{vlan <vlan_name 32>}
show igmp_snooping
forwarding
{vlan <vlan_name 32>}
Each command is listed, in detail, in the following sections.
config igmp_snooping
Purpose Used to configure IGMP snooping on the Switch.
Syntax
config igmp_snooping [<vlan_name 32> | all] {host_timeout
<sec 1-16711450> | router_timeout <sec 1-16711450> |
leave_timer <sec 1-16711450> | state [enabled | disabled]}
Description This command allows configuration of IGMP snooping on the
Switch.
Parameters
<vlan_name 32> The name of the VLAN for which IGMP
snooping is to be configured.
router_timeout <sec 1-16711450> Specifies the maximum
amount of time a router can be a member of a multicast group
without the Switch receiving a host membership report. The
all – Selecting this parameter will configure IGMP snooping for all
VLANs on the Switch.
host_timeout <sec 1-16711450> Specifies the maximum
amount of time a host can be a member of a multicast group
without the Switch receiving a host membership report. The
default is 260 seconds.
143
