Connection of analog RGB cable
1
DSUB 15P shrinking
terminal (Male)
Presenter side
(DSUB 15P)
RGB input terminal
unit side
(BNC)
Video output (Red)
2
3
Video output (Blue)
4
GND
5
6
GND (Red)
7
GND (Green)
8
GND (Blue)
9
10
GND
11
12
13
14
Vertical synchronizing signal
15
Red
Green
Blue
Gray
Black
R signal
G signal
B signal
Vertical synchronizing signal
Horizontal synchronizing signal
Horizontal synchronizing signal
Video output (
Green
)
6
7
8 9 10
1
11 12 13 14 15
2345
GND
Signal assignment (DSUB 15P shrinking terminal)
1
2
3
4
5
Pin No.
Name
Video output (Red)
Video output (Green)
Video output (Blue)
NC
GND
Name
GND (Red)
GND (Green)
GND (Blue)
NC
GND
Name
GND
NC
Horizontal synchronizing signal
Vertical synchronizing signal
NC
6
7
8
9
10
Pin No.
11
12
13
14
15
Pin No.
RGB input signal
10
9
8
7
6
12345
1112131415
Signal assignment
Input signal
Video signal
Horizontal synchronizing signal
Vertical synchronizing signal
Composite syncronizing signal
Analog 0.7V(p-p) 75Ω
TTL level (positive / negative polarity)
TTL level (positive / negative polarity)
TTL level (positive / negative polarity)
DSUB 15P shrinking terminal (Female)
Pin arrangement
1
2
3
4
5
Pin No.
Name
Video input (Red)
Video input (Green)
Video input (Blue)
NC
GND
Name
GND (Red)
GND (Green)
GND (Blue)
NC
GND
Name
GND
NC
Horizontal synchronizing/
composite synchronizing signal
Vertical synchronizing signal
NC
6
7
8
9
10
Pin No.
11
12
13
14
15
Pin No.
RGBoutput signal
