OSD Control Options
Control Description
Contrast Increases or decreases contrast.
Brightness Increases or decreases brightness.
V-Position Moves the screen up or down.
H-Position Moves the screen left or right.
Recall Defaults Returns the monitor to its default settings.
Color Balance Press or and “Select” button to select 9300, 6500, 5500, 7500
and USER. Only when selecting USER can you make adjustments to
the R/G/B content. Press Select to restore to factory default setting.
OSD Exit Escape OSD icon.
Sharpness Adjust Sharpness.
Phase Increases or decreases the snow noise of the image after auto
adjustment is made.
Clock The dot clock is fine-adjusted after auto adjust.
OSD H-Position Moves the OSD position horizontally on the screen. When the
“SELECT” button and the button is pressed, the OSD control menu
will move to the rightside of the screen. Likewise, when the “Select”
button and the button is pressed, the OSD control menu will move to
the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the
“SELECT” button and the button is pressed, the OSD control menu
will move to the top side of the screen. Likewise, when the “Select”
button and the button is pressed, the OSD control menu will move to
the lower side.
OSD Time Adjsuts the time of OSD icon stays on monitor.
Auto-Adjust Press Auto to enable this function. The Auto-Adjust will automatically
adjust V-Position, H-Position, Clock and Clock-Phase.
OSD Language Select from English, French, German ,Spanish and Japanese.
Information Description Indicates the current resolution, H-Frequency and V-Frequency.
