Table A-14. Part No. Reference Table (Continued)
Ref.No. Description PPL Name
200 MAIN BOARD (FOR USA, S.E. ASIA)
BOARD ASSY., MAIN
(FOR USA, S.E. ASIA)
200 MAIN BOARD (FOR EUROPE)
BOARD ASSY., MAIN
(FOR EUROPE)
300
POWER SUPPLY BOARD (FOR 120 V)
BOARD ASSY., POWER SUPPLY
(FOR 120V)
300
POWER SUPPLY BOARD
(FOR 220 V / 240 V)
BOARD ASSY., POWER SUPPLY
(FOR 220V/240V)
330
HARNESS HARNESS
400
POWER CABLE (VD31303SA-10A) (230
V)
POWER CABLE (VD31303SA-10A)
(230V)
401
POWER CABLE (VD31303SA-10A)
(240 V)
POWER CABLE (BS31303SA-SR-10A)
(240V)
402
AC CABLE (240 V) AC CABLE (240V)
403
POWER CABLE (VD00303SA-10A)
(220 V)
POWER CABLE (VD00303SA-10A)
(220V)
403
POWER CABLE (220 V) POWER CABLE (220V)
410
POWER CABLE POWER CABLE ASSY.
411
POWER CABLE (100 V) POWER CABLE ASSY. (100V)
412
HARNESS (220 V / 240 VAC INLET) HARNESS (220V/240V AC INLET)
450
PANEL BOARD BOARD ASSY., PANEL
500
PRINTER MECHANISM (M-4A60) PRINTER MECHANISM (M-4A60)
501
DRIVEN PULLEY PULLEY, DRIVEN
502
BASE FRAME FRAME ASSY., BASE
503
PE DETECTOR (0 V, 0 A, 0 W) DETECTOR, PE (0V, 0A, 0W,)
504
LEFT FRAME FRAME ASSY., LEFT
505
MIDDLE FRAME FRAME ASSY., MIDDLE
506
RIGHT MAIN FRAME FRAME, MAIN, RIGHT
507
BOTTOM MAIN FRAME FRAME, MAIN, BOTTOM
508
CARRIAGE B CARRIAGE ASSY.; B
509
GEAR CHANGE LEVER LEVER, CHANGE, GEAR
510
SUPPORT CHANGE LEVER LEVER, CHANGE, SUPPORT
511
PAPER LOAD SHAFT SHAFT, PAPER LOAD
512
TIMING BELT TIMINGBELT
513
BK HEAD CABLE CABLE, HEAD, BK
514
YMC HEAD CABLE CABLE, HEAD, YMC
515
PRINT HEAD, IJ48-0CA (COLOR) PRINT HEAD, IJ48-0CA (COLOR)
516
PRINT HEAD, IJ64-0AA (BLACK) PRINT HEAD, IJ64-0AA (BLACK)
517
FRONT APER GUIDE PAPER GUIDE , FRONT
518
PAPER LOADING ROLLER ROLLER ASSY., PAPER LOAD
519
PAPER LOADING ROLLER SUPPORT ROLLER, PAPER LOAD, SUPPORT
