EPSON Stylus Color 900 Revision c
Appendix Parts List 184
7.4 Parts List
Table 7-21. Parts List (1/6)
Table 7-22. Parts List (2/6)
No. Description No. Description
100 HOUSING, UPPER 119 LOCK, STACKER
101 HOUSING, LOWER 120 COMPRESSION SPRING, 2.94
102 COVER, PRINTER 121 SHIELD PLATE, MAIN, UPPER,
RIGHT
103 PAPER SUPPORT ASSY 122 SHIELD PLATE, MAIN, UPPER,
LEFT
104 HOUSING, REAR 123 GROUNDING PLATE, I/F, UPPER
105 COVER, CONNECTOR, UPPER 124 GROUNDING PLATE, I/F
106 STACKER ASSY. 125 GUIDE, I/F BOARD
107 HOUSING, PANEL, RIGHT 126 SHIELD PLATE, MAIN, UPPER, I/
F
108 KEY TOP 129 SHIELD PLATE, P/S, LOWER
109 OPTICAL PLATE 130 SHIELD PLATE, P/S, UPPER
110 SLEEVE, OPTICAL PLATE 131 GROUNDING PLATE, P/S
111 SHEET, PROTECT, PANEL 132 SHIELD PLATE, P/S, UPPER,
RIGHT
112 HOUSING, PANEL, LEFT 133 SPACER, SHIELD PLATE
113 POROUS PAD, INK EJECT, L 134 FOOT, P/S
114 POROUS PAD, INK EJECT, R 135 MOUNTING PLATE, FAN
115 LOGO PLATE 136 GUIDE, FRAME, FAN
116 COVER, POROUS PAD, INK
EJECT
137 SHIELD PLATE, I/F
117 SPACER, POROUS PAD, INK
EJECT
138 SHIELD PLATE, MAIN, LOWER
118 FOOT 139 GROUNDING PLATE, M/B
No. Description No. Description
140 GUIDE, SHIELD PLATE 410 POWER CABLE ASSY.
142 CLAMP 450 BOARD ASSY., PANEL
145 C.P.SCREW 500 PRINTER
MECHANISM(ASP)M4P10-100
146 C.B.S. SCREW 501 FRAME, UPPER
147 C.B.S. SCREW 502 FRAME, LOWER
148 C.B.S-TITE SCREW 503 FRAME ASSY., LEFT
149 C.B.S-TITE SCREW 504 FRAME, RIGHT
150 C.B.P-TITE SCREW, 3X8, F/ZN 505 FRAME, GUIDE, CR
151 C.B.P-TITE, 3X10, F/ZN 506 LEVER, PG
152 C.B.SCREW, 4X14, F/ZN 507 TORSION SPRING, 64.7
154 C.B.P-TITE SCREW, 3X6, F/ZN 508 TIMING BELT
155 C.P.P-TITE SCREW, 4X12, F/ZN 509 HOLDER, PULLEY, DRIVEN
156 C.B.(O) SCREW 4X8 F/ZG 510 PULLEY, DRIVEN
180 LABEL, CAUTION 1 511 SHAFT, PULLEY, DRIVEN
181 LABEL, ACCESSORY 512 BUSHING, PULLEY, DRIVEN
200 BOARD ASSY., MAIN 513 COMPRESSION SPRING, 48
300 BOARD ASSY., POWER
SUPPLY
514 INK SYSTEM ASSY.
330 WIRE HARNESS 515 MOTOR ASSY., PF
331 WIRE HARNESS 516 GROUNDING PLATE, FRAME,
LOWER
332 WIRE HARNESS 517 LINEAR SCALE
333 WIRE HARNESS 518 PAPER GUIDE, RIGHT
334 WIRE HARNESS 519 PAPER GUIDE, UPPER
335 FAN ASSY. 520 PAPER GUIDE, LEFT
