HDP 800 Series Card Printer/Encoders Service Manual (Rev. 5.0)
135
Reviewing the Lamination Color/Resin YMCK+L Self-Test
Step Procedure
1 Use this card to determine Lamination Placement and confirm that (a) the image
colors are properly reproduced and (b) the Resin Panel is printing properly. (Note:
The Image consists of twelve spot colors, YMC and RGB, as well as gray density
bars and thin resin lines.)
