Selecting the Card Size
Step Procedure
1 Select the appropriate card option:
• CR-80: This selection is the default form size for the Printer. This will print
a 2.125 X 3.374 image including a .04 over-bleed on each of the 4 sides
making the overall form size 2.204 X 3.452 (56 X 87.7 mm).
• Custom: This selection is used to create a custom form size from 1.0 x
3.0 to 2.204 to 3.452 (25.4 X 76.2 mm to 56 X 87.7 mm).
The dimensions of the total print area for each card size will appear in the Print
Width and Print Length boxes.
• These print area dimensions are .04" (1mm) larger than the actual card
size. This is so the Printer can overprint images to ensure they will appear
Edge-to-Edge when transferred to the card.
• For this reason, when designing a card format, always set the card size or
page size within the card design program to the exact Print Length and
Width dimensions listed in the Printer Driver.)
