13
REMOTE CONTROL (Battery Installation)
1a
1b
2
3
Remove battery tray by pressing point
(1a) inside then sliding point (1b) area at
the same time.
Pull out the battery tray.
Install or replace the button type battery
“CR2032”.
Close the battery tray.
4
1.
2.
3
4
55
56
57 59
60
61
62
63
64
65
66
67
68
69
71
72
73
7475
86
77
78
58
LOCATION OF CONTROLS - REMOTE CONTROL
70
79
80
81
82
83
84
85
76
Note: Pull out insulation tag from the
button battery tray before operating the
remote control.
14
LOCATION OF CONTROLS - REMOTE CONTROL (Cont.)
TIMER Button
Activates/deactivates the timer
CD Door OPEN/CLOSE Button
Opens the door while the unit is on. Other
operating elements now become
accessible, and you can insert or remove
CDs.
MOOD LIGHT Button
Press to turn on soft lighting from the CD
door.
Remote Control Transmitter
EQ Button
Selects FLAT, POP, ROCK, JAZZ and
DISCO sound effects
POWER ON/STANDBY Button
Switches the system on or off
1 - 9, 0/+10 NUMERIC Buttons
Recalls TUNER preset stations / recalls
CD tracks
55.
56.
57.
58.
59.
60.
61.
62.
63.
64.
65.
66.
67.
68.
69.
73.
FOLDER Button
Selects MP3 album (reverse)
PLAY/PAUSE Button
To play CD, start CD playback / short
interruption of CD playback
MUTE Button
Mutes the sound
VOLUME (+) Button
Increases volume
CD / TUNER SKIP Button
-Manual tuning up to stations, station
search operation (Forward)
-CD forward title selection, forward
search operation
70.
71.
72.
74.
75.
76.
77.
MEM/PGM Button
For tuner memory / CD program
MP3 MODE Button
Selects title & artist or album in MP3
mode
REPEAT Button
Repeats 1 track / 1 disc / all discs in CD
mode
DISC-2 Button
Press to play CD tray-2
ST/MO / FOLDER Button
-Stereo/Mono switching for FM stations
-Selects MP3 album (Forward)
DISC-3 Button
Press to play CD tray-3
VOLUME (-) Button
Reduces volume
DYNAMICBASS Button
Press for a rich bass sound
SURROUND Button
Press to turn the surround sound ON
or OFF. The indicator lights while
surround is ON.
CD / TUNER SKIP Button
-Manual tuning down to stations,
station search operation (Backward)
-CD backward title selection,
backward search operation
TUNER / BAND Button
Activates TUNER mode and selects
the reception band
78.
STOP Button
Interrupting the CD playback /
clearing the CD programme
