440
5. Close the top cover.
You should hear a click when it is returned to its original position.
6. Reset the pad assy usage counter.
The usage counter must be reset by an administrator. For details, refer to "Resetting the
Usage Counter" (page 157).
7.6.4 Replacing the Pick Roller
1. Remove any documents from the ADF paper chute.
2. Remove the ADF paper chute.
3. Push the ADF release button, then hold both sides of the top cover and lift it open.
ATTENTION
Be careful that the top cover does not shut on your fingers.
ATTENTION
Be careful that the top cover does not shut on your fingers.
