Firmware version 1.0.0.23 DP715/DP710 User Manual Page 40 of 52
If set to Yes, config file is authenticated before acceptance. This protects the
configuration from an unauthorized change.
Used for firmware encryption. Should be 32 digit in hexadecimal representation. End
user should keep it blank.
The user specifies SSL certificate used for SIP over TLS in X.509 format.
The user specifies SSL private key used for SIP over TLS in X.509 format.
The user specifies password to protect the private key above.
The user specifies the Auto Configuration Server’s URL (TR-069 protocol)
The user specifies the ACS Username
The user specifies the ACS password
Default is No. If set to YES, device will send inform packets to the ACS
Frequency that the inform packets will be sent out to the ACS
Connection Request
Username
Set a user name for the ACS to connect to this device
Connection Request
Password
Set a password for the ACS to connect to this device
The user specifies SSL certificate used to connect to the ACS server via HTTPS in X.509
format.
The user specifies SSL private key used to connect to the ACS server via HTTPS in
X.509 format.
Using these settings, users can configure tone frequencies and cadence according to
their preference. By default they are set to North American frequencies. Configure these
settings with known values to avoid uncomfortable high pitch sounds. ON is the period of
ringing (“On time” in ‘ms’) while OFF is the period of silence. In order to set a continuous
tone, OFF should be zero. Otherwise it will ring ON ms and a pause of OFF ms and then
repeat the pattern.
Example configuration for N.A. Dialtone:
f1=350@-13,f2=440@-13,c=0/0;
Syntax: f1=freq@vol, f2=freq@vol, c=on1/off1-on2/off2-on3/off3; [...]
(Note: freq: 0 - 4000Hz; vol: -30 - 0dBm)
Default is No.If set to “Yes”, the configuration update via keypad is disabled.
Default is No. Disables the voice prompt configuration.
Default is No. Disables the Direct IP Call function.
URI or IP address of the NTP (Network Time Protocol) server. This parameter
synchronizes the date and time.
Allow DHCP option 42
to override NTP server
Default No. Enables the DHCP server to handle the NTP Server via Option 42
