FIRMWARE VERSION 1.0.4.23 GXP1100/GXP1105 USER MANUAL Page 12 of 46
USING THE GXP1100/GXP1105
GETTING FAMILAR WITH THE KEYPAD
The following table describes the buttons used on the GXP1100/GXP1105 keypad.
Table 4: GXP1100/GXP1105 KEYPAD DEFINITIONS
Hold. Place active call on hold, or resume the call on hold.
Flash. Flash key can be used for multiple purposes.
• Call waiting. Bring up a new line; or answer the second incoming call.
• 3-way Conference. Establish 3-way conference when FLASH key is configured
as CONF. Before using the Flash key for 3-way conference, "Enable Flash key as
CONF" option has to be set to "Yes" under web GUI->Advanced Settings.
Transfer. Transfer an active call to another number.
Message. Retrieve voicemail messages.
Programmable hard key. It can be configured for multiple purposes: Speed dial,
Dial DTMF, VMsg, Call Return, 3-way Conference, Transfer, Intercom.
Mute. Press to mute/unmute an active call.
Send. It can be used as Send or Redial.
• Send. Enter the digits and then press Send to dial out the number.
• Redial. Redial when there is a previously dialed call.
Volume. Press "-" or "+" to adjust the volume.
0 - 9, *, #
Standard phone keypad.
