FEATURES
The GXW410x is a next generation IP voice and video gateway that features full interoperability with
leading IP-PBXs, Soft-switches and SIP platforms. The GXW410x series gateways offer superb voice and
video quality, traditional telephony functionality, simple configuration, feature-rich functionality and an
additional video port that enables the gateway to act as a video surveillance gateway.
SOFTWARE FEATURES OVERVIEW
• 4 and 8 FXO port media gateways
• Video surveillance port
• External power supply
• Two RJ-45 ports (switched or routed)
• TFTP and HTTP firmware upgrade support
• Multiple SIP accounts, multiple SIP profiles (choice of 3 profiles per account)
• Supports Audio Codecs: G711U/A, G723, G729A/B and GSM
• Supports Video Codecs: H.264
• G.168 – echo cancellation
• Flexible DTMF transmission: In Audio, RFC2833, SIP Info or any combination of the 3
• Selectable, multiple LBR coders per channel
• T.38 compliant
HARDWARE SPECIFICATION
TABLE 4: HARDWARE SPECIFICATION OF GXW410X
LAN interface
2xRJ45 10/100Mbps
LED
8 LEDs (GREEN)
Universal Switching
Power Adapter
Input: 100-240V AC, 50/60Hz, 0.5A Max
Output: 12V DC, 1.25A
UL certified
Dimension
225mm (L) x 172mm (W) x 42mm (H)
Weight
0.29 lbs (3.5 oz)
Temperature
32~104°F
0~40°C
Humidity
10% - 90% (non-condensing)
Compliance
FCC, CE
