Removal and Installation
8-61
HP DesignJets 1050C and 1055CM Printers Service Manual
5. Remove the screw and clip (item 2) from the back of the Printer and
disconnect the Ink Leak Detector Cable Connector (item 1) as shown in
Figure 65. The Ink Leak Detector Cable can now be removed completely
Figure 65: Leak Detector Cable
6. Unclip the Leak Detector from the Printer and remove as shown in
Figure 66.
Figure 66: Leak Detector
1
2
