DesignJet 2800CP
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Other Accessories
Software
C7779-60044 ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series
(German)
C7779-60045 ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series
(French)
C7779-60046 ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series
(Spanish)
C7779-60047 ZEHRaster software for UNIX - Allows TIFF and JPEG printing on DesignJet 700 series, 1000 series, and CP series
(Italian)
Take-Up Reel
145
C6246A Take-up reel kit for DesignJet 2000CP/2500CP - Includes take-up reel spindle assembly, left and right take-up reel
supports, take-up reel sensor assembly, empty core tubes, and media weight tubes
Other Internal Parts
Bushing
146
C3195-40076 Cutter bushing - Connects cutter assembly to slider rod
Cable
147
C4704-60024 Ribbon cable assembly - Has 28 pin (F) connectors - 23.5cm (9.3 inches) long
Clamp
148
C4723-40086 Trailing cable holder
Cutter
149
C4704-60299 Cutter assembly - Auto cutter for rollfeed paper - Only for serial prefix ESA and ESB
150
C4723-60244 Cutter assembly - Auto cutter for rollfeed paper
Elevator
151
C4704-60033 Elevator platform assembly - Raises and lowers ink cartridges to fill the print heads - Located on left side of plotter
Enclosure
152
C4704-60067 Cutter enclosure - Mounted above entry platen
Flag
153
C4704-40007 Service station flag - Spring loaded flag on right side of service station
Refill Assembly
154
C4723-60249 Refill assembly - Mounted inside the left hand cover - Includes motor and gears
Service Station
155
C4723-60276 Service station assembly
Spring
156
C4704-80009 Service station spring
Trim
157
C4704-60113 Right trim assembly - At right of entry platen
158
C4723-60111 Left trim assembly - At left of entry platen
Paper Drive Parts
Bail
192
C4704-60329 Bail assembly - Mounting strip assembly for the starwheel mount assemblies (Not included) - Extends width of plotter
Bearing
193
1410-0708 Sleeve bearing - Used on left end of overdrive assembly
Bushing
194
C1633-40082 Pincharm spring retaining bushing
