LaserJet 4100DTN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
Internal Components
Cable
98
RG5-5349-000CN Cable assembly - 13 pin (F) connector to 12 pin (F) connector - 30.8cm (12.1 inches) long
99
RG5-5350-000CN Laser/scanner assembly laser cable
100
RG5-5351-000CN Formatter assembly cable
101
RG5-5357-000CN Feed/registration sensor assembly cable
102
RG5-5358-000CN Duplexer cable
103
RG5-5470-000CN Cable assembly - Has two 10 pin (F) connectors - 33.0cm (13 inches) long
104
RG5-5471-000CN Antenna cable
Clip
105
RB2-4969-000CN Registration assembly grounding clip
106
RB2-4986-000CN Fan mounting clip
Connector
107
RG5-3712-000CN Lower tray connector and cable
Cover
108
RG5-2669-050CN Feeder cover left side
RG5-5274-000CN Front right side inner cover assembly
Drive Assembly
110
RG5-5087-000CN Print drive gear assembly
111
RG5-5095-000CN Delivery drive assembly
Fan
112
RH7-1442-000CN Main cooling fan
Frame
113
RG5-5072-000CN Tray 2 upper frame assembly
114
RG5-5278-000CN Right side tray 2 frame assembly with paper size PCB
Gear Assembly
115
RG5-3723-000CN MP tray coupler gear and mounting plate
Guide
116
RB1-8704-030CN Bottom cable guide
Hardware
117
RB2-5013-000CN Screw - M4 x 8.3mm
Holder
118
RB2-4992-000CN Formatter board cable holder - Right side
Insulator
RB2-4975-000CN Insulation sheet - Insulator sheet for controller board
Laser/Scanner
120
RB1-8699-000CN Laser/scanner shutter
Lever Assembly
121
RB2-4837-000CN Tray size sensing lever assembly
Motor
122
RH7-1504-000CN Main motor assembly
Mount
123
RB2-4996-000CN Thermistor mount for TH3
