Overview
ATI RADEON 7500 PCI Graphics Controller Installation Guide
Connector Pinouts
Table 1-2 contains a listing of the pins and signals found on the standard 15-pin VGA connector and
the DVI-I to VGA adaptor (part number 209815-001 not included in kit).
Table 1-2 Standard 15-Pin VGA Connector Pinout
Pin No. Signal
1 RED VIDEO
2 GREEN VIDEO
3 BLUE VIDEO
4 No connector
5 GROUND
6 GROUND
7 GROUND
8 GROUND
9 +5V SUPPLY
10 GROUND
11 No connector
12 BI-DIRECTIONAL DATA
13 HORIZONTAL SYNC or COMPOSITE SYNC
14 VERTICAL SYNC (VCLK)
15 DATA CLOCK
Chapter 1 3
