Working with Media
Changing the Core Tube on the Take Up Reel Accessory
3-37
Alternatively you can use an empty media cardboard core.
NOTE:Ensure the Take Up Core is pushed firmly into both media guides.
NOTE:If you want to use a three inch cardboard core then use the 3 inch core
adaptors shown below.
12'' / 305mm
42'' / 1067mm
+ 54''/1372mm=
+ 36''/915mm=
+ 50''/1270mm=
C472350b
Take Up Core
3 inch core adaptors
Left hand media
guide
Take Up Reel spindle
Right hand
media guide
