HP 17” Color Monitor User’s Guide
Technical Specifications
12 English
Technical Specifications
1. Use the standard image sizes to avoid distortion of the displayed image.
PICTURE TUBE
Size 17-inch flat screen/ 15.7-inch viewable image
Phosphorous Red, Green, Blue short persistence
Dot pitch 0.28 mm
Face Plate Anti-glare, multilayer coating
INPUT SIGNAL
Video 0.7 Vp p analog RGB, no setup.
Synchronization Separated H/V (TTL level), H/V mixed (TTL level)
INTERFACE
Input Connector 15-pin mini D-SUB
SCANNING FREQUENCY
Horizontal 30 to 70 kHz
Vertical 50 to 120 Hz
MAX. RESOLUTION (H
×
V)
1280
×
1024 (60 Hz)
WARM-UP TIME
30 minutes to reach optimum performance level
PIXEL CLOCK
110 MHz
IMAGE SIZE
Standard size
1
:306(H) x 230(V) mm
Maximum size: 320(H) x 240(V) mm
POWER SOURCE
AC 90 to 264 V, 47 to 63 Hz, 100W (max), less than 10 W in Suspend mode, less than 5 W in Sleep mode,
less than 1 W in Off mode
OPERATING ENVIRONMENT
Temperature 0
°
C to 40
°
C (operating)
- 40
°
C to +65
°
C (storage)
Humidity 10% RH through 80% RH (without condensation)
CABINET DIMENSIONS
422(H)
×
420(W)
×
426(D) mm (with stand)
WEIGHT
17 kg
TILT/SWIVEL STAND
Tilt Angle - 5
°
to +13
°
Swivel Angle
±
45
°
