Hardware
Installing the LCS60
Configure the LCS60
Configure the LCS60 as directed in Chapters 3 through 7.
LAN Connections
Ethernet
Connections to an Ethernet LAN are made by a standard DB15 Ethernet trans-
ceiver cable. The MVME197 processor board supports a single LAN connection.
Refer to Figure 2-7 and follow the steps in the procedure below to connect the
LAN to an LCS60. Label all connections. This data is required for correct confi-
guration.
1 . When using the MVME197 interface, connect one end of the DB15 cable to
the "Ethernet 0" connector on the MVME712M module at the back of the
LCS60.
2 . Connect the other end of the cable to the Ethernet transceiver at the LAN.
3 . After configuring the system (as described in Chapters 3 through 7), verify
the connections as specified in Chapter 9.
Issue 3 2-29
