Hard Drives
Hard DrivesHard Drives
Hard Drives
160-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
250-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
320-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
500-GB Serial ATA 3.0-Gb/s NCQ, Smart IV (7200 rpm)
System Memory
System MemorySystem Memory
System Memory
1-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (2 x 1GB)
2-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 2GB)
3-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (1 x 2GB, 1x1GB)
4-GB DDR3 Synch DRAM PC3-10600 (1066/1333-MHz) Non-ECC (2 x 2GB)
NOTE:
NOTE: NOTE:
NOTE:
Memory runs at maximum system supported speed of 1066 MHz.
Storage
StorageStorage
Storage
–
One or more of the
following (see Storage
section below)
Optical Drives (Serial ATA)
Optical Drives (Serial ATA)Optical Drives (Serial ATA)
Optical Drives (Serial ATA)
SATA DVD-ROM Drive
SATA SuperMulti LightScribe DVD Writer Drive
Input Devices
Input DevicesInput Devices
Input Devices
Keyboard
KeyboardKeyboard
Keyboard
Compaq USB Standard Keyboard
HP Mini USB Keyboard (optional)
Mouse
MouseMouse
Mouse
Compaq USB Optical Scroll Mouse
Audio
AudioAudio
Audio
Realtek ALC662 High Definition audio codec
3D audio compliant and HD Audio compatible
HP USB Thin Powered Speakers
Communication
CommunicationCommunication
Communication
Integrated Realtek RTL8103EL 10/100 Ethernet Controller
Intel Gigabit CT Desktop NIC (optional)
LSI PCIe x1 Hi-Speed 56K International SoftModem (optional)
HP PCIe Wireless 802.11b/g/n
Graphics
GraphicsGraphics
Graphics
Integrated Intel Graphics Media Accelerator 4500
NVIDIA GeForce G210 HDMI PCIe x16 Graphics Card
ATI Radeon HD 4350 HDMI PCIe x16 Graphics Card
Miscellaneous
MiscellaneousMiscellaneous
Miscellaneous
HP FireWire / IEEE 1394 PCI Card (full height)
HP Serial/Parallel PCI Card (full height)
QuickSpecs
Compaq 500B Microtower PC
Compaq 500B Microtower PCCompaq 500B Microtower PC
Compaq 500B Microtower PC
Standard Features and Configurable Components (availability may vary by country)
DA - 13418 North America — Version 2 — October 30, 2009
Page 4
