Set Traps
For the Set Traps Diagnostic, the CDB values should be set as follows:
v PF-1
v SelfTest - 0
v DevOfl - Any value allowed and ignored
v UnitOfl - Any value allowed and ignored
v Parameter List Length - X000A
Table 97 shows the parameter data to be sent with the Set Traps diagnostic.
Table 97. Set Traps Diagnostic Parameter Data
76543210
0 Page Code (80h)
1 Reserved
2
Page Length (0006h)
3
4
Diagnostic ID (0190h)
5
6 Flags (0000000b)
Cartridge
Required
(0)
7 Reserved
8
Fault Symptom Code
9
Receive Diagnostics Results: There are no diagnostic results for the Set Traps
diagnostic.
Chapter 2. Command Support 77
