16.7 Interrupt Registers
This section contains information about interrupt registers. See Chapter 11 for theory of operation information.
Table 95. Chip Status CSR
Byte Offsets: 083:082h
Bit Name R/W Description
0 PM_D0 R/W1TC
Power Management Transition to D0. The 21555 sets this bit when it is
transitioned from a low power D1 or D2 state to a high power D0 state.
When the corresponding Chip IRQ Mask bit for this event is a 0, the
21555 asserts s_inta_l to indicate to the subsystem that it is being
brought to a higher power state.
Writing a 1 clears this bit to a 0. Writing a 0 has no effect.
Reset value is 0
1
Subsystem
Event
R/W1TC
Generic subsystem event bit. The 21555 sets this bit when a
deasserting (rising) edge is detected on s_pme_l. When s_pme_l is
not used for power management purposes, it may be used to signal
some other subsystem event. When the Chip IRQ Mask bit for this
event is a 0, the 21555 asserts p_inta_l to indicate to the host system
that this signal was deasserted.
Writing a 1 clears this bit to a 0. Writing a 0 has not effect.
Reset value is 0
15:2 Reserved R Reserved. Returns 0 when read.
Table 96. Chip Set IRQ Mask Register
Byte Offsets: 085:084h
Bit Name R/W Description
0 Set_D0M R/W1TS
• When 0, signal s_inta_l is asserted on the 21555’s secondary
interface when the corresponding chip event bit is a 1, indicating
a return of power state to D0.
• When 1, the corresponding chip event bit does not generate an
interrupt.
Writing a 1 to a bit in this register sets the Chip IRQ Mask bit to 1.
Writing a 0 to any bit in this register has no effect. Reading this
register returns the current status of the Chip IRQ Mask bits.
• Reset value is 1
1 Set_Sstat R/W1TS
• When 0, signal p_inta_l is asserted on the 21555’s primary
interface when the corresponding chip event bit is a 1, indicating
a deasserting edge on s_pme_l.
• When 1, the corresponding chip event bit does not generate an
interrupt.
Writing a 1 to a bit in this register sets the Chip IRQ Mask bit to 1.
Writing a 0 to any bit in this register has no effect. Reading this
register returns the current status of the Chip IRQ Mask bits.
• Reset value is 1
15:2 Reserved R Reserved. Returns 0 when read.
