SPECIFICATIONS
Image device : 1/3-inch, interline-transfer CCD x 3
Effective picture element : 768 (H) x 493 (V)
[U Ver.]
380000 pixels
752 (H) x 582 (V)
[E Ver.]
440000 pixels
Color separation system : F1.4 prism
Lens mount : C mount
Output video signal : NTSC [U Ver.]
PAL [E Ver.]
VIDEO output : 1 Vp-p, 75 Ω
Y/C output : Y : 1 Vp-p, 75 Ω
C : 0.286 Vp-p, 75 Ω [U Ver.]
0.3 Vp-p, 75
Ω
[E Ver.]
RGB/COMPONENT : R/G/B : 0.7 Vp-p, 75 Ω
ON SYNC : 0.3 Vp-p, 75 Ω
COMP. Y : 1 Vp-p, 75 Ω
R-Y/B-Y :0.7 Vp-p, 75 Ω [U Ver.]
0.525 Vp-p, 75
Ω
[E Ver.]
C. SYNC : 2 Vp-p, 75 Ω
Color system : Wide band color difference system
External sync system : VBS, 1 Vp-p, 75 Ω, positive elec-
tric signal (with color lock)
HD/VD, 4 Vp-p, 75 Ω, negative
electric signal (without color lock)
EXT TRIGGER
FLASH output : Open connector, negative electric
signal
WEN output : 5 Vp-p, negative electric signal
FREEZE input : 5 Vp-p, negative electric signal
Contour compensation system
: H - Both effective
V - One effective
Standard cable length : 5 m
Max. cable length : 25 m (operation only guaranteed)
Registration : 0.05% (except lens)
Sensitivity : F5.6 2000 lx
Min. luminance for object : 16 lx (calculated value)
S/N ratio : 59 dB (TYP) [U Ver.]
57 dB (TYP) [E Ver.]
Horizontal resolution : 700 TVL
Power supply : AC120V, 50/60 Hz [U Ver.]
Power consumption : 22 W [U Ver.]
AC230V
`
, 50/60 Hz [E Ver.]
Operating temperatures : –5˚C to 45˚C
Mass : Camera head 170 ˝
CCU 2.7 k˝
Accessories : Camera head x 1
Camera mounting bracket x 1
Screw x 2
Camera control unit x 1
Camera cable (5 m) x 1
AC cable (2 m) x 1
Label x 1
Instructions x 1
Warranty card x 1 [U Ver.] only
