pecifications.
Printer Option
IP-432
Type Embedded
Print Speed 45 ppm
Resolution 600x600 dpi
Paper Size A5–A3
PDL PCL5e/6 compatible, PS3 (optional)
CPU Intel Celeron 300A, 300 Mhz
Host Interface IEEE1284/RJ45 (standard with 7145)
Printer Drivers Win95/98/Me/NT4.0/2000,XP, Mac OS (PS3 only)
Network Protocols TCP/IP, LPD/LPR,IPX/SPX, IPP, FTPserver, FTPclient, SNMPclient, HTTP,SNMP, EtherTalk
Standard Memory 64 MB (max. 192 MB)
Special Functions Print Quantity Setting, Orientation, Paper Tray selection, Output Paper Size selection, Zoom, Exit Tray
selection, Sort/Staple/Punch (with finisher),Alternate Sort (without finisher),Duplex, Password Printing (with
optional HHD), Overlay, Booklet, Front/Back Cover, N-up,Watermark, Smoothing, OHP,PC-fax (with
optional FK-102),Toner Save, etc.
Network Card standard with main body (10baseT/100baseTX)
Hard Disk PCMCIA, max. 2 GB
PS-344 Optional PostScript up-grade (PS3)
Memory Extension 64/128 MB
Cluster Printing KPPM (optional software)
Fax Option
FK-102
Compatibility SUPER G3
Modem Speed 33.6 Kbps
Original Scanning Speed 2 seconds (A4)
Transmission Speed 3 seconds (A4R)
Scanning Resolution max. 16pels/nmx15.4lines/mm
Transmission Resolution max. 400 x 400 dpi
Half Tones 256 grey scales
Coding MH,MR, MMR, JBIG
Memory 2 MB standard (16 MB max.)
Original Size/Recording Size max.A3
One-Touch Dials 40
Abbreviated Dials 200
Program,Group Dials 40
Special Functions
Broadcasting Transmission, Quick Memory Transmission (fax while scan), Rotational Transmission/ Receiving,
Book Copy Transmission, 2-in-1 Transmission/Recording, Duplex Recording, Remote Multi-Printing, PC-Fax with
IP-432 & HDD, FL-102 (Q3 2003) option installs second line for simultaneous sending and receiving etc.
Environment
The Konica 7145 is more than small and powerful. It is
also gentle to the environment. Energy saving features
and a toner recycling system make the Konica 7145 a
resource saver for the office.The Konica 7145 has been
recognised for it’s environmental friendliness, achieving
Energy Star certification.Its specifications even meet the
new Blue Angel standards.
Bottle-type toner is easy to replace,eliminating
messy clean up.
Power Saving
Though the Konica 7145 is fast and ready to output at a
flash,it also features innovations for reducing power
consumption.The Power Saver button on the control
panel,for example,puts the machine in sleep mode
when not needed for use.Touching any key immediately
powers up the machine for use. Other power saving
features include Auto Low Power and Auto Shut Off.
* The availability of the special functions listed here depends on the optional accessories installed on the Konica 7145.
All indications in this leaflet regarding paper,original and output capacities refer to the maximum capacity based on standard 80 g/m
2
paper.
Specifications subject to change without notice.
