Konica Minolta copiers and multi-functional
peripherals are designed with the environment in mind.
This product has earned the ENERGY STAR for energy efficiency.
ENERGY STAR is a U.S. registered mark.
The world’s first environmental-protection label,
introduced in Germany in 1978, certifies that products
and services have low environmental impact.
These products comply with the security requirements
of ISO15408 (EAL Level 3).
*
The ISO 15408 certification applies only to IT security
capabilities. This certification is NOT a product guarantee.
ISO15408 (EAL Level 3) Certification
Requirements for safe use
• Please read and follow the instruction manual to ensure safe operation.
• Only operate using appropriate power supply and voltage.
• Connecting the earth wire to an inappropriate place may cause
explosion or
electric shock. Please connect accordingly (Taiwan and the
Philippines only).
Have Earned ENERGY STAR for Energy Efficiency
The Use of Recycled Materials
Production at ISO-Certified Factories
(bizhub C652DS in evaluation)
(bizhub C652DS in evaluation)
Blue Angel Mark (BAM)
System Options
Local Interface Kit
EK-604
Local Interface Kit
EK-605
*
Keyboard Holder
KH-101
Working Table
WT-506
Security Kit SC-507
Authentication Unit
AU-102
(Biometric type)
Authentication Unit
AU-201 (IC card type)
Key Counter Mount Kit 1
Upgrade kit UK-203
i-Option LK-101 v2
i-Option LK-102
i-Option LK-103 v2
i-Option LK-105
*
Not available in all areas.
Large Capacity Unit
LU-301
Increases the bizhub's
paper capacity by 3,000
sheets for paper up to A4
size and 80g/m
2
thick.
Banner Paper
Setting Guide MK-715
Used for banner printing.
(Not compatible with Finisher FS-526)
Large Capacity Unit
LU-204
Increases the bizhub's
paper capacity by 2,500
sheets for paper up to
A3 wide and 80g/m
2
thick.
Post Inserter PI-505
*
When attached to Finisher FS-526,
allows you to add white paper
cover sheet/inter sheet, and
operate the Finisher manually.
Punch Kit PK-516
Attach to Finishers FS-526 for
hole punching capability
(paper up to 300g/m
2
thick)
Punch Kit PK-517
Attach to Finishers FS-527 for hole punching
capability (paper up to 256g/m
2
thick)
Saddle Stitcher
SD-509
Attaches to
Finisher FS-527 for
saddle stitching and half
folding jobs.
Saddle Stitcher
SD-508
Attaches to FinisherFS-526
for saddle stitching, half folding
and tri-folding jobs.Its output
tray, a Universal Design feature,
allows paper removal from as
low as 381mm abovethe floor.
Finisher FS-526
A high-performance
finisher that allows you
to multi-staple up to
100sheets.
Finisher FS-527
A small, low-noise and
high-performance finisher
that allows you to multi-
staple up to 50 sheets.
Z Folding Unit
ZU-606
Includes Z-folding
function and hole
punching function.
Job Separator JS-602
*
When attached to the FS-526,
this becomes the fax/print/
copy outpt separator tray.
Job Separator JS-504
When attached to the C452, this becomes
the fax/print/copy internal output separator tray.
Fiery Image Controller IC-412
Video Interface Kit VI-505
Fax Kit FK-502
Mount Kit MK-720
Includes Fax Sub Line
Connector.
Stamp Unit SP-501
Spare
TX Marker
Stamp 2
Staples MS-10A
Staple Kit MS-5C
Staple Kit SK-602
*PI-505 and JS-602 cannot be
installed at the same time.
*Cannot be used together
with the fax sub line.
Scan Accelerator
Kit SA-502
C652/C552/C652DSC652/C552/C452/C652DS
Job Separator JS-603
When attached to the
FS-527, this becomes
the fax/print/copy output
separator tray.
Output Tray OT-503
Internet Fax
Function Specifications (Standard)
Scanning Function Specifications (Standard)
Protocol SMTP/POP3, TCP/IP
Connection Mode Full-Mode
Sending Paper Size
Max. A3 (Long Length Support: Max.1,000mm)
Recording Paper Size Max. A3
Resolution
400
✕
400dpi, 600
✕
600dpi
Colour/Grey Scale : 200
✕
200dpi, 400
✕
400dpi, 600
✕
600dpi
Interface Ethernet (10BASE-T/100BASE-TX/1000BASE-T)
Colour Support Colour Internet Fax
Format Send: TIFF-S, Receive: TIFF-F
Colour/Grey Scale: TIFF (RFC3949 Profile-C)
Type Full-Colour Scanner
Interface Ethernet (10BASE-T/100BASE-TX/1000BASE-T)
Driver TWAIN Driver (2000/XP/XP64bit)
Protocol TCP/IP (FTP, SMB, SMTP) (IPv4/IPv6)
Scanning Speed (A4 Crosswise) B&W/ Colour
Simplex: 78/78opm (300dpi), 65/55opm (600dpi) Duplex: 156/156opm (C652DS)
Scanning Size
Max. A3 (11"
✕
17")
Output Format TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS
Scanning Resolution 200dpi/300dpi/400dpi/600dpi
Main Functions
Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to SMB,
Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home,
Scan to USB, WS-Scan
Other Functions
Multi-Method Send, Authentication at the time of E-Mail send
Fax
Kit FK-502 Specifications (Optional)
Communication Super G3
Compatible Lines Public Switch Telephone Network, Fax Communication Line
Line Density
G3: 8
✕
3.85, 8
✕
7.7, 16
✕
15.4 line/mm,
600
✕
600dpi
Modem Speed 2.4kbps
-
33.6kbps
Compression
MH/MR/MMR/JBIG
Sending Paper Size Max. A3 (Long Length Support: Max.1,000mm)
Recording Paper Size
Max. A3 (Long Length Max.1,000mm - following the page division)
Transmission Speed Less than 3 sec. (A4, V.34, 33.6kbps, JBIG)
Scanning Speed (A4 Crosswise) Detailed mode: 1.0 sec.
Memory Shared with the copier
Number of Abbr. Dials 2,000
Number of Program Dials 400
Number of Group Dials 100
Sequential Multiple Station Transmission Max. 600
Fiery Image Controller IC-412 Specifications (Optional)
Type Embedded
CPU Intel Celeron M440 1.86GHz (FSB 533MHz)
Memory 512MB (Standard)
HDD
80GB
Print Speed
Same as Copy Speed (when using the same original)
Print Resolution 1,800dpi equiv.
✕
600dpi
PDL Adobe PostScript3 (PDF v1.7), PCL6
Protocol
Ethernet ( Apple Talk, TCP/IP ), HTTP/HTTPS, SSL/TLS for HTTPS, SNMP
,
SMB, Port9100 ( Bi-Directional ), IPP, LDAP, IPV6 PhaseII, SNMP v3
Support OS Windows 2000/XP/XP 64bit/Server2003/Server2003 64bit,
Vista/Vista64bit/Server2008 (utility only)/Server2008 64bit (utility only)
Mac OS X 10.3.9, 10.4 or later, UNIX/Linux
Fonts 136 European fonts
Interface
Ethernet (10BASE-T/100BASE-TX/1000BASE-T)
*
Optional Mount Kit MK-720 is required.
*
Optional Video Interface Kit VI-505 is required.
1
A4 crosswise/full size/using the first tray/scanning from the original glass surface.
bizhub C652/C552/C452/C652DS General Specifications
Type Embedded
CPU MC7448 1GHz
Memory Shared with the copier
Print Speed
Same as Copy Speed (when using the same original)
HDD 250GB (Shared with the copier)
Print Resolution 1,800dpi equiv.
✕
600dpi
PDL PCL6, PCL5, PostScript 3, XPS
Protocol
TCP/IP, IPX/SPX (NDS support), SMB (Net BEUI), LPD, IPP1.1, SNMP, HTTP
Support OS Windows NT4.0 SP6/2000, SP3/XP/XP64bit/Vista/Vista64bit/
Server2003/Server2003 64bit/Server2008/Server2008 64bit
Mac OS 9.2(PPD)/X 10.2,3,4,5/10.4,5 Intel, Linux
Fonts PCL 80 European fonts
PS 137 European Type1 fonts
Interface
Ethernet (10BASE-T/100BASE-TX/1000BASE-T), Hi-Speed USB
Printer Specifications (Standard)
Type Console
Colour Support Full-Colour
Copy Resolution Scan Main: 600dpi
✕
Sub: 600dpi
Print Main: 1,800dpi equiv.
✕
Sub: 600dpi
Gradation 256
Memory Capacity (Std./Max.) 2GB/3GB
HDD 250GB
Original Type
Sheets, Books, Objects
Max. Original Size
A3 (11"
✕
17")
Output Size
A3 Wide , A3 to A5, B6 Lengthwise, A6 Lengthwise
Thick Paper, Long Length Paper (210
✕
457.3mm
-
297
✕
1,200mm)
Image Loss
Max. 4.2mm or less for top edge, Max. 3.0mm or less for bottom edge,
Max. 3.0mm or less for right/left edges
Warm-Up Time (23°C, std. voltage)
C652/C552/C452 : 45 sec. or less C652DS : 39 sec. or less
(May vary depending on the
(The time required to start printing when both the
main power
operating environment and usage.)
and sub-power switches are turned from OFF to ON.)
30 sec. or less
(The time required to start printing when the main
power switch is ON and the sub-power switch is turned from OFF to ON.)
First Copy Time
1
Colour
C652/C652DS : 5.5 sec. or less C552 : 6.0 sec. or less C452 : 6.0 sec. or less
B/W
C652/C652DS : 3.8 sec. or less C552 : 4.3 sec. or less C452 : 4.8 sec. or less
Copy Speed Colour C652/C652DS : 50 ppm C552 : 45 ppm C452 : 45 ppm
(A4 Crosswise)
B/W C652/C652DS : 65 ppm C552 : 55 ppm C452 : 45 ppm
Copy Magnification
Fixed Same Magnification 1:1
±
0.5% or less
Scaling Up 1:1.154/1.224/1.414/2.000
Scaling Down 1:0.866/0.816/0.707/0.500
Preset 3 types
Zoom 25
-
400% (in 0.1% increments)
Lengthwise Crosswise 25
-
400% (in 0.1% increments)
Individual Settings
Paper Capacity
500 sheets (Tray 1), 500 sheets (Tray 2), 1,500 sheets (Tray 3),
(80g/m
2
paper)
1,000 sheets (Tray 4), 150 sheets (Multiple Bypass Tray)
Paper Weight Tray 1 - 4 64
-
256g/m
2
Multiple Bypass Tray 64
-
300g/m
2
Multiple Copy 1
-
9,999 sheets
Auto Duplex Type: Non-Stack Paper Size: Width/100
-
311mm(
4
"
-
12
-
1/4"),
Length/148
-
457mm(
5
-
3/4"
-
18") Paper Weight: 64
-
256g/
m
2
Power Requirements AC220
-
240V 10A(50 to 60Hz)
Max. Power Consumption
C652/C652DS : 2.1kW or less C552 : 2.0kW or less C452 : 2.0kW or less
Dimensions
[W]
✕
[D]
✕
[H]
650mm
✕
879mm
✕
1,155mm (25-1/2"
✕
34-3/4"
✕
45-1/2")
Weight
C652/C552/C452: Approx. 221kg (487-1/4lb) C652DS: Approx. 223kg (491-3/4lb)
Space Requirements
[W]
✕
[D]
988mm
✕
1,525mm (39"
✕
60")
*
Multiple Bypass Tray opened
