Specifications
Monitor MultiSync
®
LCD1700M Notes
Specifications Monitor
Picture Tube Diagonal: 17.0 inch Active Matrix; Thin Film Transistor (TFT),
Viewable Image Size: 17.0 inch Liquid Crystal Display (LCD), 0.264mm
Native Resolution (Pixel Count): 1280x1024 dot pitch; XtraView
TM
Technology; 200cd/m
2
,
white luminance; 200:1 contrast ratio,typical.
Input Signal Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors Analog input: Over 16 Million Colors Depends on display card used.
Synchronization Horizontal: 31 kHz to 81 kHz Automatically
Range Vertical: 56 Hz to 76 Hz Automatically
Resolutions Supported 640 x 480 @ 60 to 75 Hz
Some systems may not support
Resolution based on
horizontal and
800 x 600 @ 56 to 75 Hz
all modes listed.
vertical frequencies only
832 x 624 @ 56 to 75 Hz
1024 x 768 @ 56 to 75 Hz
NEC-Mitsubishi Electronics Display cites
1152 x 870 @ 56 to 75 Hz
recommended resolution at
1280 x 1024 @ 56 to 75 Hz .....................
75Hz for optimal display performance.
Active Display Area Horizontal:
338 mm/13.3 inches Dependent upon signal timing used,
(Full Scan) Vertical:
270 mm/10.6 inches and does not
include border area.
Power Supply
AC 100 – 240 V, 50-60 Hz
Current Rating 1,2 A @ 100
–
120 V/0,5 A @ 220
–
240 V
Dimensions
422 mm (W) x 451 mm (H) x 208 mm (D)
17 inches (W) x 18 inches (H) x 8.2 inches (D)
Weight 7.3 kg
16.1 lbs
Environmental Considerations
Operating Temperature: 0°C to + 40°C
Humidity: 20% to 80%
Feet: 0 to 10,000 Feet
Storage Temperature: -20°C to +60°C
Humidity: 5% to 95%
Feet: 0 to 40,000 Feet
NOTE: Technical specifications are subject to change without notice.
