• Remote monitoring (RMON), with four groups integrated:
- Statistics
- History
- Alarms
- Events
• Front-panel light emitting diodes (LEDs) to monitor the following:
- Power status
- System status
- Per-port status for the following:
1000 Mb/s link
100 Mb/s link
10 Mb/s link
Half- and full-duplex transmission
Tx/Rx activity
Management enable/disable
• Upgradeable device firmware in nonvolatile flash memory using the Trivial
File Transfer Protocol (TFTP)
IEEE 802.1Q VLANs
BayStack 350 switches support up to 64 port-based VLANs with IEEE 802.1Q
tagging available per port. When a switch port is configured to be a member of a
VLAN, it is added to a group of ports (workgroup) that belong to one broadcast
domain. You can assign different ports (and therefore the devices attached to these
ports) to different broadcast domains. This feature allows network flexibility
because you can reassign VLANs to accommodate network moves, additions, and
changes, eliminating the need to change physical cabling.
For more information about 802.1Q VLANs, see “
IEEE 802.1Q VLAN
Workgroups” on page 1-18.
