AUDIO
Item Setting
Description of setting
No. Item No. Item
700 CH1 IN LV 0000 4dB
0001 0dB ™™
0002 –20dB
701 CH2 IN LV 0000 4dB
0001 0dB ™™
0002 –20dB
702 CH1 OUT LV 0000 4dB
0001 0dB ™™
0002 –20dB
703 CH2 OUT LV 0000 4dB
0001 0dB ™™
0002 –20dB
704 EMPHASIS 0000 OFF
™™
001 ON
705 REC CUE 0000 CH1
0001 CH2
™™
0002 CH1+2
706 CUE 0000 OFF
INSERT 0001 ON
The underlined number and item are the factory settings.
33
VV
TT
RR
12
Detailed description of set-up menus
DETAILED DESCRIPTION OF SET-UP MENUS
This selects the audio input (CH1) reference setting.
This selects the audio input (CH2) reference setting.
This selects the audio output (CH1) reference setting.
This selects the audio output (CH2) reference setting.
This sets the emphasis to ON or OFF.
This selects the input signal to be recorded for CUE.
0: Audio input CH1 signal
1: Audio input CH2 signal
2: Audio input CH1 and CH2 mixed signal
This selects whether CUE is to be inserted during AUDIO INSERT.
0: CUE is not inserted and pre-recorded signals are left.
1: CUE is inserted.
