Features and specifications subject to change without notice.
Peavey Electronics Corporation • 5022 Hartley Peavey Drive • Meridian, MS • 39305
(601) 483-5365 • FAX (601) 486-1278 • www.peavey.com • EX 000130 • ©2011
Mic In to full power at the power amp. Master Volume Nom.
Full Nominal
-48 dBu -28 dBu
Line In to full power at the power amp. Master Volume Nom.
Full Nominal
-18 dBu +3 dBu
Shelving EQ
Low EQ 80 Hz ±15 dB
High EQ 12 kHz ±15 dB
Clip LEDs come on 3dB before clipping.
All controls nominal (detent)
Mic to Main 30 Hz – 20 kHz +0, -1 dB
Line to Main 20 Hz – 30 kHz +0, -1 dB
Mic to Amp 50 Hz – 20 kHz +0, -3 dB
Line to Amp 40 Hz – 20 kHz +0, -3 dB
Main = Main line output, 22 – 22kHz filter
Amp 1 = Amplifier output, loaded at 4 ohms, through AP
AUX-0025 switching amplifier filter
All controls full down.
Main <-95 dBu
Amp 1 <-70 dBu
Master Volume nominal
Main <-90 dBu
Amp 1 <-67 dBu
All controls nominal
<0.01% @ main line output, -30 dBu in mic input
<0.09% @ amp 1 with output adjusted to 45 Watts
All controls nominal
<0.005% @ main line output, +4 dBu in line input
<0.08% @ amp 1 with output adjusted to 45 Watts
80 Hz +/-12 dB
250 Hz +/-12 dB
1 kHz +/-12 dB
3 kHz +/-12 dB
10 kHz +/-12 dB
LIMIT
-6 dB
-12 dB
-18 dB
-24 dB
-30 dB
Limits amplifier power just before clipping. The limiter holds the amp
power without clipping and can be driven up to 18 dB past maximum
output.
120VAC
Both channels loaded at 8 ohms: 30 Watts RMS per ch
60 Watts Peak per ch
Both channels loaded at 4 ohms: 50 Watts RMS per ch
100 Watts Peak per ch
Domestic: 120VAC 50/60Hz 40 Watts Nominal
Export: 230VAC 50/60Hz 40 Watts Nominal
Dimensions: H x W x D
9” x 14” x 9”
14 lbs.
