Page 38
Epson Research and Development
Vancouver Design Center
S1D13505 Hardware Functional Specification
X23A-A-001-14 Issue Date: 01/02/02
6 D.C. Characteristics
Table 6-1: Absolute Maximum Ratings
Symbol Parameter Rating Units
V
DD
Supply Voltage V
SS
- 0.3 to 6.0 V
DAC V
DD
Supply Voltage V
SS
- 0.3 to 6.0 V
V
IN
Input Voltage V
SS
- 0.3 to V
DD
+ 0.5 V
V
OUT
Output Voltage V
SS
- 0.3 to V
DD
+ 0.5 V
T
STG
Storage Temperature -65 to 150
°
C
T
SOL
Solder Temperature/Time 260 for 10 sec. max at lead
°
C
Table 6-2: Recommended Operating Conditions
Symbol Parameter Condition Min Typ Max Units
V
DD
Supply Voltage V
SS
= 0 V 2.7 3.0/3.3/5.0 5.5 V
V
IN
Input Voltage V
SS
V
DD
V
T
OPR
Operating Temperature -40 25 85
°
C
