Data Sheet
2
WGSD-1022C
IEEE 802.1Q Tagged based VLAN and Port-based VLAN•
Up to 4 Trunk groups, each trunk can be up to maximum 8 port with 1.6Gbps bandwidth(Full Duplex Mode)•
IEEE 802.1d, IEEE 802.1w, classic Spanning Tree Algorithm or Rapid Spanning Tree support•
QUALITY OF SERVICE
4 priority queues on all switch ports.•
Strict priority and Weighted Round Robin (WRR) CoS policies•
QoS and bandwidth control on each port•
MULTICAST
IGMP Snooping v1 and v2•
IGMP Port and Group policy•
SECURITY
IEEE 802.1x Port-based Authentication, RADIUS server authentication•
MAC address Filtering and MAC address Binding•
Port Mirroring to monitor the incoming or outgoing traffic on a particular port•
MANAGEMENT
WEB-based, Telnet, Console Command Line management•
Access through SNMP v1 and v2c set and get requests.•
Four groups (history, statistics, alarms, and events) of embedded remote monitoring (RMON) agents for network monitoring and trafc analysis•
EMI standards comply with FCC, CE class A•
Applications
Workgroup Switch
With 8 10/100Mbps copper ports and 2 Gigabit-Ethernet fiber ports, the WGSD-1022C provides a cost-effective and high-performance solution for
power users.
NAS Clients
Backbone / Internet
P
WGSD-1022C
Workgroup Switch
VoIP Phone Printer
100Base-TX UTP
1000Base-SX/LX Fiber-optic
1000
1000
1000
File Server
