Data Sheet
2
Physical Port
• 48-Port 10/100/1000Base-T Gigabit Ethernet RJ-45
• 4 SFP slots, shared with Port-23, Port-24, Port 47 and Port-48
• Console interface for Switch basic management and setup
Layer 2 Features
• Complies with the IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE
802.3z Gigabit Ethernet standard
• Supports Auto-negotiation and Half-Duplex / Full-Duplex modes for
all 10Base-T/100Base-TX and 1000Base-T ports.
• Auto-MDI / MDI-X detection for each RJ-45 port
• Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x
PAUSE frame flow control (Full-Duplex)
• High performance of Store-and-Forward architecture, broadcast
storm control and runt/CRC filtering eliminates erroneous packets to
optimize the network bandwidth
• 8K MAC address table, automatic source address learning and ageing
• 12Mbit embedded memory for packet buffers
• Supports IEEE 802.1Q Tagged based VLAN
• Private VLAN Edge (PVE) supported
• GVRP protocol for VLAN Management
• Supports up to 8 Trunk groups, and each trunk can be up to
maximum 8 port with 1.6Gbps bandwidth (Duplex Mode)
• IEEE 802.1d, IEEE 802.1w, classic Spanning Tree Algorithm or Rapid
Spanning Tree support
• Supports the IEEE 802.1s specification for multiple spanning trees on
a single port (spanning tree by VLAN)
• Port Mirroring to monitor the incoming or outgoing traffic on a
particular port
Quality of Service
• 4 priority queues on all switch ports
• Supports for strict priority and Weighted Round Robin (WRR) CoS
policies
• Supports QoS and bandwidth control on each port
• Traffic-policing policies on the switch port
Multicast
• Supports IGMP Snooping v1 and v2
Security
• IEEE 802.1x Port-Based Authentication
• IP-Based Access Control List (ACL)
• MAC-Based Access Control List
• Port Security
Management
• WEB-based, Telnet, Console Command Line management
• SSH (Secure Shell), SSL
• Accesses through SNMPv1, v2c and v3 security Set and Gets requests
• Four groups (history, statistics, alarms, and events) of embedded remote
monitoring (RMON) agents for network monitoring and traffic analysis
• Built-in Trivial File Transfer Protocol (TFTP) client
• Virtual Cable Test (VCT) technology provides the mechanism to detect
and report potential cabling issues, such as cable opens, cable shorts,
etc. on Copper Links
Key Feature
WGSW-48040
