SpectraLink 6100 MCU: Installation and Operation: SpectraLink 6000 System
Connect power
1. Connect the power plug from the AC adapter to the jack labeled
PWR on the MCU.
Use only the provided Class II AC Adapter with output 24VDC, 1A.
For installations with more than one MCU, use an outlet strip with a
built-in power switch. This allows the MCUs to be turned on and off
together.
2. Plug the AC adapter into a 110VAC outlet or switch on the outlet
strip to apply power to the MCU.
Set switch interface type
The following steps explain how to assign a switch interface type to
the MCU. This procedure must be done on each MCU.
1. Power on the MCU with the mode switch in the
NORMAL position.
Because the MCU does not have a switch type assigned, it will
alarm (the
ERROR LED will flash along with STATUS LEDs 1, 2, 3, 4,
and
5). This should take less than 2 minutes.
2. Power off the MCU.
3. Move the mode switch to
ADMIN and power on the MCU. Within
15 seconds,
STATUS LEDs 2 and 4 will light.
4. Press the
STEP button three times.
STATUS LEDs 1, 2, and 4 must be lit. LINE LEDs 1 through 8
(indicating an unconfigured MCU) should also be lit.
If any other combination of
LINE LEDs is lit, then a switch type has
already been selected. Go to step 5 to pick the desired switch type.
5. Press the
DEL/ENTER button to select the correct switch interface
type. With each press of the
DEL/ENTER button, a different series of
LINE LEDs will be lit. Continue to press DEL/ENTER until the correct
LINE LEDs are lit. Use the following list to select the desired switch
interface.
