Instruction
Instruction Code
Operation
Execution
States
DC
DCT PSTS MACL,Dz 111110**********
110111100000zzzz
If DC = 1, MACL → Dz 1
DCF PSTS MACL,Dz 111110**********
110111110000zzzz
If DC = 0, MACL → Dz 1
PLDS Dz,MACH 111110**********
111011010000zzzz
Dz → MACH 1
DCT PLDS Dz,MACH 111110**********
111011100000zzzz
If DC = 1, Dz → MACH 1
DCF PLDS Dz,MACH 111110**********
111011110000zzzz
If DC = 0, Dz → MACH 1
PLDS Dz,MACL 111110**********
111111010000zzzz
Dz → MACL 1
DCT PLDS Dz,MACL 111110**********
111111100000zzzz
If DC = 1, Dz → MACL 1
DCF PLDS Dz,MACL 111110**********
111111110000zzzz
If DC = 0, Dz → MACL 1
PADDC Sx,Sy,Dz 111110**********
10110000xxyyzzzz
Sx + Sy + DC → Dz
Carry → DC
1 Carry
PSUBC Sx,Sy,Dz 111110**********
10100000xxyyzzzz
Sx – Sy – DC → Dz
Borrow → DC
1 Borrow
PCMP Sx,Sy 111110**********
10000100xxyy0000
Sx – Sy → DC update* 1 *
PABS Sx,Dz 111110**********
10001000xx00zzzz
If Sx < 0, 0 – Sx → Dz
If Sx > = 0, nop
1 *
PABS Sy,Dz 111110**********
1010100000yyzzzz
If Sy < 0, 0 – Sy → Dz
If Sx > = 0, nop
1 *
PRND Sx,Dz 111110**********
10011000xx00zzzz
Sx + h'00008000 → Dz
LSW of Dz → h'0000
1 *
PRND Sy,Dz 111110**********
1011100000yyzzzz
Sy + h'00008000 → Dz
LSW of Dz → h'0000
1 *
Note: * See table 2.32.
